Technical Details
| Machine Specifications | |
|---|---|
| Weight | About 7000kgs |
| Size | About 6m x 1.0m x 1.5m (length x width x height) |
| Color | Main color: blue |
| Warning color: yellow | |
| Suitable Raw Material | |
| Material | PPGI and PPGL Coils |
| Thickness | 0.4-0.6mm |
| Coil width | 610mm |
| Yield Strength | 235Mpa |
| Main Technical Parameters | |
| Diameter of forming rollers shafts | 65mm |
| Roll Forming Speed | 15-20m/min |
| Forming rollers material | No.45 steel, coated with chromed treatment |
| Cutter material | CR12 mould steel, with quenched treatment |
| Controlling system | PLC and Converter |
| Electric Power requirement | Main motor power: 4kw |
| Hydraulic unit motor power: 5.5kw | |
| Electric voltage | According to customer’s requirement |
-
Special rollers design, more precise and solid
-
Shaft diameter: 55mm or more, according to profile
-
Wall plate 18mm thick
-
Mitsubishi PLC and converter
-
Tool box and technical support
-
-
-
-
India Customer
-
Australia Customer
-
South America Customer
